QUESTION 2
NetFlow provides valuable information about network users and applications, peak usage times, and traffic routing. Which function is of NetFlow?
A. monitor configuration changes
B. monitor CPU utilization
C. monitor link utilization
D. generate traps for failure conditions
Correct Answer: CQUESTION 3
The P4S company is deploying OSPF on a point-to-multipoint Frame Relay network. The remote sites needn??t to communicate with each other and there are a relatively small number of sites (scaling is not a concern). How to configure OSPF for this topology in order to minimize the additional routing information injected into the network and keep the configuration size and complexity to a minimum?
A. Configure the link as OSPF nonbroadcast and manually configure each of the remote sites as a neighbor.
B. Configure the link as OSPF broadcast and configure the hub router to always be the designated router.
C. Configure the link as OSPF broadcast and configure a mesh group towards the remote routers.
D. Configure the link at the hub router as OSPF point-to-multipoint and at the remote routers as OSPF point-to-point.
Correct Answer: BQUESTION 4
What is high availability?
A. redundant infrastructure
B. clustering of computer systems
C. reduced MTBF
D. continuous operation of computing systems
Correct Answer: DQUESTION 5
What is the way that an OSPF ABR uses to prevent summary route information from being readvertised from an area into the network core (Area 0)?
A. It advertises only inter-area summaries to the backbone.
B. It uses poison reverse and split horizon.
C. It only sends locally originated summaries to the backbone.
D. It compares the area number on the summary LSA to the local area.
Correct Answer: CQUESTION 6
Connecting an IS-IS router to four links and redistributing 75 routes from RIP. How many LSPs will be originated by this router?
A. one LSP: containing the router information, internal routes, and external routes
B. six LSPs: one for each link, one containing router information, and one containing external routing information
C. two LSPs: one containing router information and internal routes and one containing external routes
D. three LSPs: one containing all links, one containing router information, and one containing external routing information
Correct Answer: AQUESTION 7
According to the network in this exhibit, traffic directed towards 10.1.5.1 arrives at P4S-R4. Which path will the traffic take from here?
A. It will take P4S-R2.
B. It will not take any path. P4S-R4 will drop the traffic.
C. It will take P4S-R3.
D. It will load share between P4S-R2 and P4S-R3.
Correct Answer: AQUESTION 8
You are the Cisco Network Designer in P4S. Which two characteristics are most typical of a SAN? (Choose two.)
A. NICs are used for network connectivity.
B. Servers request specific blocks of data.
C. Storage devices are directly connected to servers.
D. A fabric is used as the hardware for connecting servers to storage devices.
Correct Answer: BDQUESTION 9
The IGP next-hop reachability for a BGP route is lost but a default route is available. Assuming that BGP connectivity is maintained, what will happen to the BGP route?
A. It will be put in a hold-down state by BGP until the next hop has been updated.
B. It will be removed from the BGP table.
C. It will be considered a valid route.
D. It will be considered invalid for traffic forwarding.
Correct Answer: CQUESTION 10
In the network presented in the following exhibit, all routers are configured to perform EIGRP on all interfaces. All interface bandwidths are set to 1000, and the delays are configured as displayed. In the topology table at Router P4S-RC, you see only one path towards 10.1.1.0/24. Why Router P4S-RC only has one path in its topology table?
A. Router P4S-RB is not advertising 10.1.1.0/24 to Router P4S-RC due to split horizon.
B. Router P4S-RD is not advertising 10.1.1.0/24 to Router P4S-RC because Router P4S-RC is its feasible successor.
C. Router P4S-RD is not advertising 10.1.1.0/24 to Router P4S-RC due to split horizon.
D. Router P4S-RB is not advertising 10.1.1.0/24 to Router P4S-RC because Router P4S-RC is its feasible successor.
Correct Answer: C
There are a lot of sites provide the Cisco 352-001 exam certification and other training materials for you . Passcert is only website which can provide you Cisco 352-001 exam certification with high quality. In the guidance and help of Flydumps, you can through your Cisco 352-001 pdf the first time. The Cisco 352-001 practice test provided by Flydumps are IT experts use their extensive knowledge and experience manufacturing out. It can help your future in the IT industry to the next level.
QUESTION 11
How many broadcast segments are contained in this network according to the exhibit?
B. 2
C. 4
D. 5
Correct Answer: B QUESTION 12
Which VPN management feature would be considered to ensure that the network had the least disruption of service when making topology changes?
A. dynamic reconfiguration
B. path MTU discovery
C. auto setup
D. remote management
Correct Answer: A QUESTION 13
What information can you get from TCP flags while assessing an attack?
A. source of the attack
B. type of attack
C. target of the attack
D. priority of the attack traffic
Correct Answer: B QUESTION 14
Which two steps can be taken by the sinkhole technique? (Choose two.)
A. reverse the direction of an attack
B. redirect an attack away from its target
C. monitor attack noise, scans, and other activity
D. delay an attack from reaching its target
Correct Answer: BC QUESTION 15
In the network presented in the following exhibit, all routers are configured to run EIGRP on all links. All packets transmitted during convergence are transmitted once (there are no dropped or retransmitted packets). What is the maximum number of queries P4S-R3 might receive for 192.168.1.0/24 if the link between P4S-R1 and P4S-R2 fails?
A. four queries, one each from P4S-R2, P4S-R4, P4S-R5, and P4S-R6
B. no queries, because there aren’t any alternate paths for 192.168.1.0/24
C. seven queries, one from P4S-R2 and two each from P4S-R4, P4S-R5, and P4S-R6
D. one query, since the remote routers P4S-R4, P4S-R5, and P4S-R6 are natural stubs in EIGRP
Correct Answer: A
QUESTION 16
All routers in this network are running EIGRP according to the exhibit.
Which step is the most important to make sure that this network core will converge quickly should a link
failure occur?
A. make certain the maximum number of paths on both of the routers is two
B. make certain EIGRP is not running across non-transit links
C. add another link between the two routers with no servers and set the metric on this new link equal to the other four links
D. make certain EIGRP is running across all links
Correct Answer: B
QUESTION 17
When designing a converged network, which measures can be taken at the building access layer to help eliminate latency and ensure end-to-end quality of service can be maintained? (Choose three.)
A. rate limit voice traffic
B. onfigure spanning-tree for fast link convergence
C. isolate voice traffic on separate VLANs
D. classify and mark traffic close to the source
Correct Answer: BCD
QUESTION 18
Which two reasons are correct about building a flooding domain boundary in a link-state network? (Choose two.)
A. to increase the size of the Shortest Path First tree
B. to aggregate reachability information
C. to provide an administrative boundary between portions of the network
D. to segregate complex and rapidly changing portions of the network from one another
Correct Answer: BD
QUESTION 19
The P4S company is planning to deploy a new multicast application in its network to do real-time trading.
This application will be performed simultaneously by thousands of traders located throughout the network,
each a source of several IP multicast streams, to
carry the “sell” and “buy” trading bids. All routers in its network have full hardware support for all PIM
multicast modes.
Which mode can be used to minimize the impact of the new application on the routers in the P4S network?
A. PIM Source Specific Multicast
B. PIM Any-Source Multicast
C. PIM Dense Mode
D. PIM Bidirectional
Correct Answer: D
QUESTION 20
You work as a network technician for the P4S Ltd. Study the exhibit carefully, router P4S-RA is the hub router in a Frame Relay hub-and-spoke deployment. Configure router P4S-RA’s serial interface as a point-to-multipoint interface, and it is servicing three spoke routers. The link between Router P4S-RC and the frame provider experiences a service disruption, which causes the interface on Router P4S-RC to go down. How does Router P4S-RA learn of this failure in the network and how does it react?
A. If OAM is configured between Router P4S-RA and Router P4S-RC, router P4S-RA will be notified of the failure after three missed OAM packets. After the third OAM packet is missed, the frame PVC becomes inactive, and this event terminates the routing process neighbor relationship established between Router P4S-RA and Router P4S-RC.
B. Router P4S-RA does not detect the failure in the network and its interface continues to remain in an operational state. If routing is configured over this link, Router P4S-RA must wait for the neighbor relationship to time-out before updating its routing table to account for the lost router and its networks.
C. Router P4S-RA must wait for a full LMI status update from the provider frame switch before it is notified
about the PVC status.
Once the full LMI status message is received, the routing process neighbor relationship between
Router P4S-RA and Router
P4S-RC is immediately terminated.
D. Router P4S-RA immediately detects the failure via LMI notification and its interface is placed in a non-operational state. If routing is configured over this link, the neighbor relationship is terminated and the routing table is updated. The change is then propagated as appropriate to the rest of the network.
Correct Answer: B
QUESTION 21
You are the Cisco Network Designer in P4S. Which two settings must be configured in order to use the GUI to configure Call Admission Control with voice applications? (Choose two.)
A. QoS must be set to Silver
B. WMM must be enabled
C. QoS must be set to Gold
D. QoS must be set to Platinum
Correct Answer: BD
QUESTION 22
In this network presented in the following exhibit, all routers are configured to perform EIGRP on all interfaces. All interface bandwidths are set to 1000, and the delays are configured as displayed. In the topology table at router P4S-RC, only one path can be seen towards 10.1.1.0/24. Which description is correct?
A. Router P4S-RB is not advertising 10.1.1.0/24 to router P4S-RC due to a split horizon
B. EIGRP should advertise all available paths to 10.1.1.0/24 in the local topology table to all neighbors so this condition is a bug
C. Router P4S-RD is not advertising 10.1.1.0/24 to Router P4S-RC due to a split horizon
D. Router P4S-RC should have two paths to 10.1.1.0/24, while routers P4S-RB and P4S-RD should each have only one path, indicating a route filter has been applied on Router P4S-RC
Correct Answer: C
QUESTION 23
Which three types of LSA could each trigger a partial SPF? (Choose three.)
A. type 2 LSA (Network Link Advertisements)
B. type 3 LSA (ABR Summary Link Advertisements)
C. type 4 LSA (ASBR Summary Link Advertisements)
D. type 5 LSA (Autonomous System External Link Advertisements)
Correct Answer: BCD
QUESTION 24
You are a network technician for the P4S company, study the exhibit carefully. P4S-R1 is redistributing 10.1.5.0/24 into Area 1 in this network. Which LSA containing 10.1.5.0/24 will P4S-R6 have in its database?
A. P4S-R6 will have a border router (type 4) LSA in its local database for 10.1.5.0/24.
B. P4S-R6 will have an NSSA external (type 7) LSA in its local database for 10.1.5.0/24.
C. P4S-R6 will have an external (type 5) LSA for 10.1.5.0/24 in its local database.
D. P4S-R6 will not have any LSAs containing 10.1.5.0/24.
Correct Answer: D
QUESTION 25
You are a network technician for the P4S Ltd. Study the exhibit carefully. All links provided in the network
are equal cost, and P4S-R1 is configured to use per packet load sharing. One-way latencies for each route
are displayed on the diagram.
Which option is true about packets sent from Network A to Network B?
A. Network B may receive out-of-order packets due to excessive latency on the P4S-R4- P4S-R3 link.
B. P4S-R1 will not use P4S-R4 and P4S-R3, because it will detect delayed TCP ACK packets coming from that path.
C. Any out-of-order packets will be buffered and sent in order by CBWFQ, configured on Router P4S-R1.
D. Any out-of-order packets will be buffered and sent in order by CBWFQ, configured on Router P4S-R3.
Correct Answer: A
